SES-5 Satellite (Standard Definition)

Orbital Position—5 degrees East longitude
Frequency Band—Ku band (linear polarization)
Antenna Size—1.2-meter or larger recommended
Downlink Frequency—12015.0 MHz (12.0150 GHz)
Downlink polarity—Vertical
Modulation—DVB-S QPSK
Symbol rate—29.95 MSym/sec
FEC—3/4
Video Encoding—MPEG 4 SD

SD Channels

1201     AF: English - French.
Set receiver to output left audio for English
Set receiver to output right audio for French

1202     AF: Amharic - Portuguese
Set receiver to output left audio for Amharic
Set receiver to output right audio for Portuguese

1206     AF: Swahili - Malagasy
Set receiver to output left audio for Swahili
Set receiver to output right audio for Malagasy

Hotbird 13 Satellite (High Definition)

Orbital Position—13 degrees East longitude
Frequency Band—Ku band (linear polarization)
Antenna Size—1.0-meter or larger recommended
Downlink Frequency—11568.25 MHz (11.56825 GHz)
Transponder—93
Downlink polarity—Horizontal
Modulation—DVB-S2 8PSK
Symbol rate—27.500 MSym/sec
FEC—3/4
Video Encoding—MPEG 4 HD

HD Channels

1619     Church of Jesus Christ   (AAC audio encoding)
Audio 1:  English, PID 6192
Audio 2:  Portuguese, PID 6193
Audio 3:  French, PID 6194
Audio 4:  Malagasy, PID 6195
